DOWNLOAD BROCHURE

Download the Official Skyworth EV Brochure

Specifications

Battery 70.65 kWh LFP
Cooling Mode of Battery System Liquid Cooling
Range 300 Km
Drive motor type PMSM
Peak power (kw) / torque (N.m) 120/350
Driving mode RWD
Rear axle type Electric axle
Chassis High strenth steel body
Front suspension type Transverse spring independent front suspension
Rear suspension type Longitudinal 3-piece leaf spring
Body Size (L × W × H) (mm) 6040 × 2020 × 2700
Wheelbase (mm) 3665
Total Mass (kg) 4490
Approach Angle / Departure Angle (°) 21 / 17
Front / Rear Overhang (mm) 1020 / 1355
Ground Clearance (mm) 220
Maximum Speed (km/h) 110
Maximum Climbing Angle 20°
Wheel specification 215/75 R16LT 12RP
Wheels Aluminum alloy wheel
Front / rear brake type Front disc / Rear drum
Parking brake Central drum brake
Regenerative braking Yes
Up-Hill Assist Yes
ABS Yes
EBD Yes
Driver's seat belt reminder Yes
Driver / All passenger three-point safety belt Yes
Non-Skid Plate Yes (Aluminum)
Body Size (L × W × H) (mm) 6040 × 2020 × 2700
Wheelbase (mm) 3665
Total Mass (kg) 4490
Approach Angle / Departure Angle (°) 21 / 17
Front / Rear Overhang (mm) 1020 / 1355
Front / Rear Track (mm) 1720 / 1716
Ground Clearance (mm) 220
Maximum Speed (km/h) 110
Maximum Climbing Angle / Climbing Speed 20 / 20
HILL ASSIST Yes
Driver's seat belt not fastened reminder Yes
ABS+EBD Yes
Driver / all passenger three-point safety belt Yes
Aluminum alloy floor Yes
